Shocker 40K Gooseneck Surge Air Hitch & Shift Lock Coupler for 3" Ball
Rated for your tow
40,000 lbs GTW · 8,000 lbs TW· 40,000 lbs GTW · 8,000 lbs TW
$2,183.98
$2,284.78 save $100.80
or as low as $182/mo with flexible financing — 4, 6, or 12 months. Options at checkout.
Easy Install
Completely replaces your factory gooseneck stem & coupler with Gooseneck Surge Air System & Coupler. Installs in Minutes.
Fits 3" gooseneck hitch balls
& has 3 height adjustment holes. (Standard coupler extends 3" forward from your factory coupler).
Custom Fit
Available for 100mm Square, 4" Square & Crank style gooseneck stems. - If you have a round stem, check out our Shocker Goose Air Hitch for 2-5/16" ball.
Shock Dampening & Absorbing Action
Effectively absorbs the jerking, tugging, bumps and damaging forces experienced when towing on rough roads & concrete highway with a typical hard connection.
Stop destroying your trailer and cargo.
Every bump, pothole, and expansion joint sends a violent jolt through your trailer frame, damaging cargo and wearing out your truck. Shocker Air Ride Hitches absorb that punishment at the coupling, before it reaches your trailer.
Load heavy up front and tow it every day, and you feel it in the truck. The forward-back jerk off every hard stop, the pounding through frost heaves, the wear that stacks up on both rigs. The Surge Air Gooseneck 40K Heavy Duty is the flagship of the Shocker lineup, rated for 40,000 lbs GTW with 8,000 lbs of tongue weight, the highest capacities Shocker makes. Its square-4-5-inch stem carries a patented Shift Lock coupler built for 3-inch gooseneck balls, so hotshot operators, equipment haulers, and commercial heavy-duty crews get real margin where a 30K hitch runs out of room.
Key Highlights
- 40,000 lbs GTW and 8,000 lb tongue weight, the most capacity Shocker builds
- Shift Lock coupler built for 3-inch gooseneck balls only
- Grips the ball from both sides with a lock indicator you can read at a glance
- Real patents: #'s 11,370,257 B1 and D898,628
- Patented air spring soaks up the forward-back jerk before it reaches the truck
- square-4-5-inch stem swaps in for your factory inner stem in minutes
- Heavy-wall, thick-gauge steel built for daily heavy hauling
- In stock in Canada and shipping direct, no border wait
What's Included
- Shocker 40K Gooseneck Surge Air Hitch with built-in heavy-duty airbag and dual bump cushions
- square-4-5-inch heavy-wall replacement inner tube stem
- Shift Lock coupler rated for 40,000 lbs on 3-inch ball
- Schrader air valve
- Installation instructions
Not Included
- —3-inch gooseneck ball (must be installed in the truck bed; verify rating matches your load)
- —Air compressor or pressure gauge (sold separately)
- —Truck-bed reinforcement (verify your bed-mount rating supports 40K hauling)
Installation
Watch the official install walkthrough for this hitch — the exact steps and tools, straight from the manufacturer.
When a 30K Hitch Runs Out of Room
Most gooseneck trailers top out around 25K to 30K GTW and ride fine on the Standard 30K hitch. But load a skid steer on a tilt-deck gooseneck, a multi-axle commercial trailer, oilfield equipment, or a hot shot load pushing the upper end of Class 5, and a 30K-rated hitch leaves you no margin. The 40K HD gives you 10,000 lbs more GTW headroom and 2,000 lbs more tongue capacity, plus a 3-inch ball coupler matched to the larger balls on 35K-class commercial gooseneck trailers. This is the hitch for operators who load heavy and tow every day.
Surge Air, Heavy-Duty Engineered
Airbag That Kills the Forward-Back Jerk
The same patented surge-air setup scaled for 40,000 lbs loads. A heavy-duty air spring soaks up the forward-back jerk between truck bed and trailer stem, the motion that beats up both rigs.
Shift Lock for 3-inch Balls
Patented dual-side capture grips the 3" gooseneck ball from both sides at once, so there's no guessing on a heavy hookup. A visual lock indicator shows you it's engaged at a glance.
Heavy-Wall Stem
Thicker-wall square-4-5-inch built to take the higher load and the harder tongue forces of heavy commercial hauling.
Tunes From Loaded to Empty
Add air for a fully loaded heavy haul, bleed it off for the empty deadhead home. One hitch dials in from peak load to bobtail.
Built for Heavy Commercial Use
If you're towing more than 30K with a gooseneck, this is your hitch.
- Hotshot truckers running 35K-class commercial gooseneck trailers
- Equipment haulers moving skid steers and excavators
- Commercial industrial transporters
- Oilfield, drilling, and construction equipment fleets
- Operators with 3-inch ball trailers (Class 5 and up)
- Anyone towing near the upper limits of Class 5 gooseneck capacity
3-inch Ball vs. 2-5/16-inch Ball
The 40K HD needs a 3-inch gooseneck ball, bigger and heavier than the standard 2-5/16-inch.
3-inch Gooseneck Ball (this line)
Required to run the 40K HD. Bigger contact surface, higher capacity, and common on commercial heavy-duty goosenecks and Class 5 equipment trailers.
2-5/16-inch Gooseneck Ball (30K lines)
Standard on Class 4 and lower-end Class 5 trailers, and used on the surge-air-gooseneck-standard-30k, offset, and shift-lock lines. It cannot run with this 40K hitch.
Engineered for Daily Heavy Hauling
Every part of the 40K HD is upsized over the 30K platform: thicker stem walls, larger pivot bushings, a higher-capacity airbag, and a coupler rated for 40,000 lbs of tow capacity and 8,000 lbs of tongue weight. It isn't a 30K hitch wearing a bigger rating sticker. It's a different chassis for operators who hit the upper limits of gooseneck towing every day. Backed by Shocker Hitch's 60-day satisfaction guarantee.
